The ASM1062 is ASMedia’s second generation Serial ATA Advantage HCI controller, bridges PCI Express Gen2 x2 to two ports of Serial ATA 6Gps, enables Serial ATA PHY up to 6Gps high speed interface, supports SRIS (Separate Refclk Independent SSC) function, complies with Serial ATA Revision 3.2 Specification. ASM1062 is highly integrated with ASMedia PCI Express and SATA 6Gbps self-designed PHYs. ASM1062 can be applied on PC, mobile, servers, IPC, consumer electronic devices, storage devices, and communication applications.

Engaged in High Speed I/O solution and storage application development, ASMedia Technology is committed to enlarging product portfolio with introducing SATA 6Gbps Port Multiplier products. ASM1092R is Serial ATA RAID port multiplier controller, supporting one host ports and two devices ports, enabling Serial ATA PHY up to 6Gbps high speed interface, following Serial ATA Revision 3.0 Specification. It is used for SATA port expansion and performance aggregation. ASM1092R is uses ASMedia first generation proprietary Hydra technology, supporting RAID0 (Strip), RAID1 (Mirror), JBOD and Span (BIG) with low power and high efficient RAID operation, easy configurable scheme through GUI, completely the free loading for the system CPU. ASM1092R is useful for SATA port expansion and performance booster, not only for internal system but also for external storage application.

Engaged in High Speed I/O solution and storage application development, ASMedia Technology is committed to enlarging product portfolio with introducing SATA 6Gbps Port Multiplier products. ASM1092 is Serial ATA port multiplier controller, supporting one host ports and two device drives, enabling Serial ATA PHY up to 6Gbps high speed interface, following Serial ATA Revision 3.0 Specification, completely the free loading for the system CPU, using for SATA port expansion, not only for internal system but also for external storage application.

Engaged in Gigabit Data transfer Speed I/O solution development, Asmedia Technology is committed to enlarging product portfolio with introducing USB3.2 Gen1 Hub controller Products. The ASM1074, the four downstream ports USB3.2 Gen1 Hub Controller, highly integrated with ASMedia SuperSpeed USB3.0 and USB2.0 self-design PHYs, enables high speed PHY interface up to 5Gbps, following Universal Serial Bus 3.0 Revision 1.0 Specification.

ASM1352R integrates ASMedia’s proprietary HydraTek technology, supporting RAID0 (Strip), RAID1 (Mirror), JBOD and Span (BIG) with low power and high efficiency RAID operation, easily configurable modes through GUI, completely free of resource loading on the system CPU. ASM1352R is useful for USB to SATA port expansion and performance boost, not only for internal design but also for external storage application.

ASMedia ASM3142 is the next generation Universal Serial Bus xHCI host controller, bridging PCI Express to USB3.1 Gen-II, compliant with USB3.1 Specification Revision 1.0 and Intel eXtensible Host Controller Interface specification revision 1.1. It also supports backward compatible with legacy USB function and devices, compliant with USB Attach SCSI Protocol revision 1.0, supporting the function of debugport on port A of USB. ASMedia ASM3142 also supports the new feature of USB3.1 Gen2, named Multiple INs to achieve fully utilization rate of 10Gbps data rate, taking advantage of the available bandwidth of USB3.1 Gen2 bus. ASM3142 supports two USB3.1 Gen-II ports and perform trusting high speed bandwidth with PCI Express Gen-III x2 supporting. It uses advance process with low voltage supply, following standard PCI Express/USB bus power management and advance chip power management to reduce total power consumption efficiently under idle/standby state. ASM3142 integrates ASMedia self-designed PCI Express/SuperSpeed USB/USB2.0 PHY, supporting in box driver of Microsoft® Windows and various Linux kernels. The application of ASM3142 includes Motherboard, Desktop PC, Notebooks, Workstations, Servers, Add-in cards, PCI Express based embedded platform.
